Allen-Bradley 845G-F3B8HS016KU Single-Turn Feedback Absolute Encoder

Manufacturer:Allen-Bradley

Model Number:845G-F3B8HS016KU

Type:Single-Turn Feedback Absolute Encoder

Measurement Range:360 degrees

Resolution:16 bits

Output Signal:Digital Output

Operating Voltage:5VDC

Operating Temperature Range:-20°C to +85°C

Enclosure Rating:IP65

Mounting:Flange Mount

Weight:0.3 kg

Dimensions:60 mm x 60 mm x 30 mm

    The Allen-Bradley 845G-F3B8HS016KU Single-Turn Feedback Absolute Encoder combines precision engineering with robust design, ensuring optimal performance under demanding industrial conditions. With its high resolution of 16 bits, this encoder delivers precise positioning feedback that is essential for modern automation systems.

    Engineered for reliability and durability, the encoder features an IP67 protection rating, safeguarding against dust and water ingress, which makes it suitable for a wide range of industrial applications. Its compact size of 44 mm x 80 mm x 25 mm allows for easy integration into existing machinery without compromising space efficiency.

    The Allen-Bradley 845G-F3B8HS016KU supports multiple output interfaces including SSI and BiSS, offering flexibility in system design and compatibility with various controllers and PLCs. Operating at a voltage of 24 VDC, this encoder is compatible with most industrial power supply standards.

    Installation and setup are straightforward, thanks to clear documentation and intuitive design. The encoder’s lightweight build at just 0.25 kg ensures ease of handling during installation and maintenance processes. Moreover, its operating temperature range of -20°C to +85°C enables reliable operation across diverse environmental conditions.

    Whether you’re upgrading an existing system or building a new one, the Allen-Bradley 845G-F3B8HS016KU offers unparalleled accuracy and reliability, setting a new standard in industrial encoder technology.
