Allen-Bradley 844D-B6CC1DR – Module

Manufacturer:Rockwell Automation

Model:844D-B6CC1DR

Incremental Output:Pulse Count: 2000 PPR

Operating Frequency:Up to 100 kHz

Supply Voltage:5V DC ±10%

Shaft Diameter:8mm

Shaft Material:Stainless Steel

Connection Type:Push-On Terminal Block

Protection Rating:IP65

Weight:0.2 kg

Dimensions:30mm (L) x 30mm (W) x 25mm (H)

    The Rockwell Automation 844D-B6CC1DR is a high-frequency incremental optical encoder designed to meet the stringent requirements of industrial automation systems. With its robust construction and precise measurement capabilities, it ensures accurate position feedback under challenging operating conditions.

    This encoder boasts a resolution of up to 2000 counts per revolution, making it suitable for applications demanding high accuracy. Its push-pull, HTL output signal format ensures reliable communication with control systems.

    Designed for ease of installation, the 844D-B6CC1DR features a compact, rugged housing that can withstand harsh environments. Its steel shaft and durable design guarantee long-term reliability.

    Optimized for a wide operating voltage range of 5V to 24V DC, this encoder can be integrated into various power supply scenarios without compromising performance.

    With its high frequency range of up to 50kHz, the encoder is capable of handling fast-moving machinery and robotic systems. This makes it an ideal choice for applications in manufacturing, packaging, and assembly lines.
