Input Voltage:342-528 Volts AC rms (3 Phase); 380-480 Volts nom DC
Input Current (nom rms):90.1 Amperes
DC Input Current:105 Amperes
Continuous Output Current (0-peak):135 Amperes
AC Input Frequency:47-63 Hertz
Continuous Output Power (nom):56 kWatts
Total Capacitance:4500 Microfarads
Dimensions:25.37 x 13.07 x 11.29 in (644.5 x 331.9 x 286.7 mm)
Weight:37.2 kg (82 lbs)
The Allen-Bradley 2099-BM09-S is a high-powered servo drive within the 2099 Kinetix 7000 series. This drive is specifically engineered for applications that require robust, reliable motor control, particularly in harsh industrial settings. Its Kinetix Integrated Motion technology ensures precision and efficiency, ideal for tasks requiring high torque and power.
Certified to operate under stringent international standards including CE, C-TICK, CUL, KC, and UL, this servo drive meets global safety and quality benchmarks. Key features include a removable DC-to-DC converter, protected by a common mode capacitor and MOVs input filter cap, ensuring long-term durability and operational integrity.
Designed with user safety in mind, the drive includes a safety torque-off output, which can be activated in emergency situations to protect equipment and personnel. The dimensions of the drive are optimized for space-efficient installation, making it suitable for a wide range of industrial machinery and systems.
The drive supports SERCOS interface for seamless communication and control within complex automation setups, enhancing system efficiency and reducing setup time. With a continuous output current of 135 Amperes and a nominal output power of 56 kW, this servo drive is well-suited for heavy-duty applications.
For easy maintenance and upgrades, the design incorporates user-friendly access to critical components, including the removable DC-to-DC converter and input filters. The robust build quality, combined with advanced safety features and high-performance capabilities, makes the Allen-Bradley 2099-BM09-S a top choice for industrial automation projects.
