NEC DFSM – 0245

Motor Type:Servo Motor

Brand:NEC

Model Number:DFSM-0245-202A

Max Power (kW):2.5

Rated Voltage (V):230

Rated Current (A):4.5

Operating Frequency (Hz):50/60

Torque Capacity (Nm):30

Rotation Speed (rpm):3000

Motor Size (mm):120 x 110 x 140

Incorporated Technology:High-precision Ball Bearing

Protection Class:IP65

Control Interface:RS-232C/RS-485

Operating Temperature (°C):-20 to 60

Weight (kg):4.8

    The NEC DFSM-0245-202A SERVO MOTOR is engineered to deliver exceptional performance in demanding precision control applications. This motor boasts a high power density ratio, making it ideal for applications where space is limited but precision is paramount.

    Equipped with advanced control algorithms and featuring a high-precision ball bearing design, the DFSM-0245-202A ensures smooth operation and reduced wear, resulting in longer service life and enhanced reliability.

    With a wide operating temperature range from -20°C to 60°C and IP65 protection class, this motor can withstand harsh environments, ensuring continuous operation even in challenging conditions.

    The inclusion of an RS-232C/RS-485 control interface facilitates seamless integration with various automation systems, offering users flexibility in controlling and monitoring the motor’s performance.

    Whether in industrial machinery, robotics, or any field requiring high-precision motion control, the NEC DFSM-0245-202A SERVO MOTOR delivers outstanding performance, backed by NEC’s commitment to quality and innovation.
