MULTILIN 565-5-5-O-A Feeder Management Relay

Manufacturer:General Electric Multilin (GE)

Model Number:565-5-5-O-A

Maximum Power Supply:50 Watts

Measurements Bandwidth:0-120 Hz

Phase Overcurrent Protection:Timed Overcurrent Pickup Range 25-250% of CT in Steps of 1%

Undervoltage Alarm and Trip Pickup:101 to 125% in steps of 1%

Ground Overcurrent Protection:Time Dial 32 Selections

Weight:Approximately 20 lbs

Burn In Temperature:60°C for 24 Hours

Ground Current Input:Momentary 20 x CT Input Rating for 3 Seconds

Saturation:20 Times CT

Storage Temperature:-30 to 80 °C

Undervoltage Alarm and Trip Delay:0.1 to 25.5 seconds in Steps of 0.1 Seconds

Voltage Inputs VT Burden:Less than 0.2 VA at Rated Input Voltage

Max Voltage for Analog Outputs:30 VDC or p-pAC

    The Multilin 565-5-5-O-A is a digital feeder management relay designed for industrial applications. It provides enhanced protection against overcurrent, undervoltage, and ground faults, ensuring the reliability and safety of electrical systems. With a maximum power supply of 50 Watts, this relay can handle high-frequency applications up to 120 Hz. Its phase overcurrent protection offers a timed overcurrent pickup range from 25-250% of CT in steps of 1%, making it suitable for a wide range of industrial settings. The relay also features an isolated analog output range, software selectable between 0-1 mA and 4-20 mA, providing flexible integration options. Operating within a temperature range of -30 to 80 °C, the Multilin 565-5-5-O-A is built to withstand harsh environmental conditions. The display accuracy for load currents is ± 3% from 25-100% CT primary, ensuring precise readings and efficient system management. With a frequency measurement accuracy of ± 0.1 Hz, it guarantees stable and reliable performance. This advanced feeder management relay is the ideal choice for professionals looking for a robust solution to protect their electrical systems.
