Allen Bradley 1746-NIO4V SLC500 High Resolution Analog Combination Module

In stock

This high resolution analog combination module from Allen Bradley is designed for use with SLC500 series controllers, offering precise input and output control for industrial applications. Ideal for environments where accuracy and reliability are paramount.

Model Type:SLC500

Model Number:1746-NIO4V

Manufacturer:Allen Bradley

Module Type:High Resolution Analog Combination Module

Number Of Channels:2 (Input), 2 (Output)

Input Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:Plus/Minus 7.5 VDC Or 7.5 VAC RMS (Maximum)

Input Range:-20 To 20 MA

Absolute Input Current:-30 To 30 MA (Maximum)

Output Range:-10 To 10 V – 1 LSB

Full Scale Output:10 VDC

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 55 MA

The Allen Bradley 1746-NIO4V module is an indispensable component for any SLC500 controller setup. It is meticulously engineered to deliver superior accuracy and reliability in various industrial settings. This module supports two channels for input and output operations, each capable of handling high resolution analog signals. With its wide voltage and current ranges, it can adapt to a broad spectrum of industrial applications.

Designed with stringent standards in mind, this analog combination module ensures that all components operate within safe limits, providing overvoltage protection up to 7.5 VAC RMS. Its compact design makes it easy to integrate into existing systems without requiring extensive modifications.

Installation is straightforward thanks to clear documentation and user-friendly interfaces provided by Allen Bradley. Regular maintenance is minimal due to the robust construction of the module, which is built to withstand harsh industrial environments.

Optimized for performance, this module is a testament to Allen Bradley’s commitment to excellence in industrial automation solutions.
