ABB – Module

Product Type:Relay Module

Model:SGX-116-1

Manufacturer:ABB

Operating Voltage:110V AC/DC

Contact Rating:250V AC, 10A

Number of Relays:16

Environmental Rating:IP20

Operating Temperature Range:-25°C to +60°C

Relay Life Expectancy:10,000,000 cycles

    The ABB SGX-116-1 Relay Module is specifically engineered for high-reliability applications in power distribution systems. Its advanced algorithm ensures precise detection of overloads, short-circuits, and unbalances, providing robust protection against potential hazards.

    With an impressive power rating of 3 kA at 240VAC, it is capable of handling demanding loads without compromise. The wide operational voltage range from 100V to 600V AC/DC allows for versatile installation across various electrical infrastructures.

    Featuring three types of protection—overload, short-circuit, and unbalance—it offers comprehensive coverage for system integrity and safety. The module’s ability to operate within extreme temperature conditions (-25°C to +60°C) and withstand high humidity (up to 95% non-condensing) ensures reliability in challenging environments.

    For seamless integration and data exchange, the ABB SGX-116-1 Relay Module supports RS-485 Modbus RTU communication interface. This feature enables easy configuration and monitoring through a variety of industrial control systems, enhancing system efficiency and maintenance.

    Crafted with precision and durability, this relay module stands out for its compact design, making it suitable for space-constrained installations. The lightweight construction (0.2kg) facilitates quick and efficient installation processes, ensuring minimal downtime during setup or replacement.
