A-B 20F11NC015JA0NNNNN PowerFlex Air Cooled 753 AC Drive, High-Efficiency Motor Control

In stock

The Allen-Bradley 20F11NC015JA0NNNNN PowerFlex 753 AC Drive offers advanced control and protection for industrial motor applications. It is ideal for environments requiring robust performance in variable speed control for pumps, fans, conveyors, and more.

Brand:Allen-Bradley

Series:20F11

Voltage:400V AC

Phase:3

Amps:15.5

kW:7.5

HP:10

Frame😀

Enclosure:Flange Mount – Front Chassis = IP 20, NEMA/UL Type 1, Rear Heatsink = IP66, NEMA/UL Type 4X/12 for indoor/outdoor use

Interface Module:Full Numeric LCD w/Brake

IGBT:Yes

Rating:Filtered A & B Frames (Optional) C, D, & E Frames (Standard)

Network Type:None

Control:Enhanced

This PowerFlex Air Cooled 753 AC Drive from Allen-Bradley offers an enhanced control system that optimizes motor performance across a wide range of applications.

It features a program-only LCD interface module that simplifies operation and monitoring.

With its robust enclosure, this drive is capable of withstanding harsh environmental conditions, making it suitable for both indoor and outdoor use.

The flange mount design ensures easy installation and maintenance.

Equipped with an IGBT (Insulated Gate Bipolar Transistor), this drive ensures efficient power conversion and superior motor control.

Additionally, it supports filtered A & B frames (optional) and standard C, D, & E frames, providing flexible configuration options to meet specific project requirements.

A-B 20F11NC015JA0NNNNN
