Yokogawa AAR145 – S50 S1 RTD/P…

Number of input channels:16

Isolated channels:Yes

Switching input signals:RTD/POT selectable individually for CH1 to CH16

Measurement current:RTD: 1 mA

Allowable input voltage:±5 V

Maximum current consumption:350 mA (5 V DC)

External connection:Dedicated cable

Suffix Code:S1=Standard type, S=Standard type, 5=No explosion protection, 0=Basic type

Weight:0.3 kg

    The YOKOGAWA AAR145-S50 S1 Input Module is engineered for enhanced accuracy and reliability in industrial control systems. With its advanced signal handling capabilities, it ensures seamless integration into complex PLC networks.

    Each of the 16 isolated channels supports individual selection of RTD or POT signals, providing flexibility and precision in monitoring temperature changes or resistance values.

    Equipped with a maximum measurement current of 1 mA for RTD inputs, this module offers high sensitivity, making it ideal for applications requiring fine-tuned response.

    The module is designed for robust performance, supporting an allowable input voltage range of ±5 V, ensuring compatibility with a wide variety of industrial power sources.

    Efficient power management ensures minimal current consumption of 350 mA at 5 V DC, reducing system load and enhancing overall efficiency. Its compact design and dedicated cable connection facilitate easy installation and maintenance.
