Tektronix 5B40 – Others

Frequency Range:0.1 µHz to 20 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary

Resolution:1 µHz

Amplitude Range:20 mVpp to 10 Vpp

Output Impedance:50 Ω

Vertical Resolution:14-bit

Memory Depth:8 Mpts

Phase Shift:±10°

    The Tektronix 5B40 Arbitrary Function Generator is an indispensable tool for engineers and technicians working in industrial control systems. With its wide frequency range from 0 Hz to 20 MHz, it supports a variety of waveform types including sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms. This generator ensures high accuracy and reliability, making it suitable for precision testing and calibration in research and development environments. Its 14-bit vertical resolution and 1 Mpoint memory depth enable detailed signal generation, while the phase shift capability of 0 to 360 degrees offers versatility for different applications. The generator also includes sweep modes such as linear, logarithmic, and list, providing flexibility for various testing scenarios. Designed for ease of use, the Tektronix 5B40 comes with intuitive controls and a user-friendly interface, ensuring quick setup and operation. With its robust construction and high-performance specifications, the Tektronix 5B40 is the perfect choice for professionals requiring precision and reliability in their test and measurement equipment.
