Siemens – I/O

CPU Type:314 Compact

Interface:MPI

DI/DO Channels:16/16

AI/AO Channels:4/1

Power Supply:24V DC

Working Memory:32 KBytes

Operating Temperature:-25°C to +60°C

Dimensions (WxHxD):144 x 150 x 220 mm

    The Siemens SIMATIC S7-300 CPU 314 Compact Module is a pivotal component for streamlined industrial control systems, boasting high-speed processing capabilities and versatile I/O configurations. This compact module is engineered to support a wide range of applications, from manufacturing lines to process control environments, ensuring precision and reliability in every operation.

    Equipped with a robust MPI interface, this module facilitates seamless communication between devices, enabling efficient data exchange and process coordination. The integrated 24V DC power supply ensures consistent power delivery, minimizing downtime and enhancing system stability.

    With 16 digital inputs and 16 digital outputs, this CPU module provides ample connectivity options, allowing for precise control over actuators and sensors. The inclusion of 4 analog inputs and 1 analog output caters to applications requiring fine-tuned control over processes, such as temperature or pressure monitoring.

    Featuring a substantial 32KByte working memory, this module ensures ample space for programming and storing critical data, supporting complex control algorithms without compromising performance. Its wide operating temperature range (-25°C to +60°C) makes it suitable for a variety of industrial settings, ensuring reliable operation under diverse environmental conditions.

    Designed with efficiency and sustainability in mind, the CPU 314 Compact Module consumes ≤ 35W, contributing to lower energy costs and reduced environmental impact. Moreover, its compact dimensions (94 x 123 x 26.4mm) facilitate easy integration into existing control cabinets, minimizing installation time and space requirements.
