Siemens – Board

Module Type:Drive Power Board

Manufacturer:Siemens

Model:E89110-F1391-C3-F

Series:6DM1001-0WB00-2

Operating Voltage:AC/DC

Current Capacity:Up to 100A

Cooling Method:Air Cooling

Communication Interface:Profinet

Control System Compatibility:Siemens S7-1500, S7-1200

Environmental Conditions:Temperature Range: -20°C to 60°C

Certifications:CE, UL, ISO 9001

    The SIEMENS E89110-F1391-C3-F 6DM1001-0WB00-2 Drive Power Board is a key component in modern industrial automation systems, designed for demanding applications requiring robust performance and reliability. This compact yet powerful module is equipped with advanced control algorithms and high-efficiency power conversion technology, enabling it to deliver precise and smooth operation under various conditions.

    Featuring a DC 24V supply voltage and a current capacity of 10A, this drive power board is capable of handling up to 1000 W of load capacity, making it suitable for a wide range of applications from machine tools to conveyor systems.

    Operated within an extended temperature range of -20°C to +50°C, the board ensures stable performance even in harsh environments. It supports RS485 Modbus communication, facilitating seamless integration with other industrial devices and systems.

    With an IP20 protection class, the board is protected against solid foreign objects but requires careful handling when exposed to liquids or dust. Its compact design allows for easy installation in confined spaces, enhancing system flexibility.

    In summary, the SIEMENS E89110-F1391-C3-F 6DM1001-0WB00-2 Drive Power Board is an essential piece of equipment for achieving high performance and reliability in industrial automation systems, offering a balance between efficiency, durability, and versatility.
