Siemens – Module

Type:Digital Output

Model:6ES7132-4BD01-0AA0

Module ID:6ES7132-4BD01-0AA0

Supplier Type:Siemens

Extended Product Type:Other

Lifecycle Status:Active

Net Weight (kg):0.077 lb

Product Group:4520

Group Code:R111

Class:-

Packing Unit:1 piece

Compatible BU-Type:A0

Colour Code:CC02

Substitute Value Output:Output module compatible with SIMATIC ET 200SP

Diagnostic Features:Short-circuit to L+, Ground Wire Break, Supply Voltage Monitoring

Power Supply:24V DC

Current Rating:0.5A

Number of Outputs:8

Operating Frequency:0.1~600Hz

RFI Resistance:Yes

DC BUS Sharing Capability:Flexible

Protection:Complete Protection

Standard MicroSD Card Compatibility:LOGO! Soft Comfort V8 or higher

Ethernet Connectivity:Integrated

Web Server Support:Yes

Data Logging Functionality:Available

User-Defined Web Pages:Support

Modular Expandability:Yes

Compatibility with Fieldbus Modules:Optional (DeviceNet, Profibus, LonWorks, CANopen)

    The Siemens Digital Output Module 6ES7132-4BD01-0AA0 is a critical component in industrial automation systems, designed for seamless integration with SIMATIC ET 200SP systems. This module is equipped with eight digital output channels, each capable of handling up to 0.5A at 24V DC, making it suitable for a wide range of applications requiring precise control signals.

    Featuring a source output type (PNP), this module ensures efficient power management and reduced wiring complexity, enhancing system reliability and efficiency. Its ability to diagnose common faults such as short circuits and wire breaks provides proactive maintenance and operational safety.

    With its compact design and lightweight structure, the module is easy to install and maintain, contributing to a streamlined and efficient automation setup. The inclusion of an integrated Ethernet interface facilitates connectivity with other devices and systems, enabling advanced control strategies and remote monitoring capabilities.

    Equipped with a user-friendly interface and diagnostic functions, this module simplifies troubleshooting and maintenance processes. Its compatibility with various fieldbus modules (such as DeviceNet, Profibus, LonWorks, and CANopen) ensures seamless integration with existing automation networks, offering flexibility and scalability for future expansion.

    Designed for durability and long-term reliability, the Siemens Digital Output Module meets stringent industrial standards, ensuring consistent performance across demanding environments. Its robust construction and advanced diagnostic features make it an indispensable tool for optimizing industrial automation processes, enhancing productivity, and reducing downtime.
