Number of Inputs (DI):16
Voltage Range (DI):24V DC
Current Rating (DI):Sink/Sourced
Number of Outputs (DO):16
Voltage Range (DO):24V DC
Current Rating (DO):0.75A/point
Module Compatibility:S7-22X CPUs
Relay Configuration:Relay
Operating Voltage:5-30V DC
Operating Frequency:Up to 1 kHz
Environmental Conditions:Temperature range -25°C to +60°C
Dimensions (WxDxH):100mm x 90mm x 35mm
Weight:0.2kg
Mounting Type:Panel Mount
The Siemens 6ES7 223-1PH22-0XA8 is an essential component in the realm of industrial automation, designed to seamlessly integrate into S7-22X CPU systems. This Digital I/O module is equipped with 16 digital inputs and 16 digital outputs, providing versatile connectivity options.
Featuring a compact yet robust design, this module supports Sink/Sourced input types, ensuring reliable signal processing in demanding environments. The outputs are equipped with relays, delivering precise control over external devices.
With a specified voltage range of 5-30V DC and 250V AC, this module is highly adaptable to various industrial applications. Its compatibility with 24V DC input makes it ideal for a wide array of control systems.
The Siemens 6ES7 223-1PH22-0XA8 is meticulously engineered for efficiency and reliability. Its lightweight design and compact size facilitate easy installation and integration into existing automation setups, enhancing operational flexibility and performance.
This Digital I/O module is not just a piece of hardware; it’s a testament to Siemens’ commitment to innovation and excellence in industrial automation solutions. It is designed to meet the stringent requirements of modern manufacturing processes, offering unparalleled performance and reliability.
