P+F KCD2-SR-EX2 Industrial Switch Amplifier, 24V DC Supply & Barrier Isolation

Product Type:Switch Amplifier

Model ID:KCD2-SR-EX2

P+F Type Designation:Extended

Power Supply:24 V DC (Power Rail)

Input Types:Dry Contact or NAMUR

Output Type:Relay Contact

Line Fault Detection (LFD):Present

Housing Width:12.5 mm

Safety Compliance:Up to SIL 2 according to IEC 61508

Signal Type:Digital Input

Rated Voltage:19…30 V DC

Power Consumption:≤ 600 mW

Connection Method:Power Rail or Terminals 9+, 10-

Mass:Approx. 100 g

Mounting Option:On 35 mm DIN mounting rail

    The P+F KCD2-SR-EX2 is an advanced automation switch tailored for industrial environments, offering unparalleled precision and reliability in control systems. Its robust design ensures compatibility with a wide array of applications, making it an indispensable component for enhancing system safety and operational efficiency.

    Featuring a 2-channel isolated barrier, the switch ensures electrical isolation between input and output circuits, significantly reducing the risk of short circuits and enhancing system reliability. The 24 V DC supply (Power Rail) provides a stable power source, ensuring consistent performance under various operating conditions.

    With support for dry contact or NAMUR inputs, the P+F KCD2-SR-EX2 accommodates diverse input types, enabling seamless integration with different sensor technologies. The relay contact output ensures reliable signal transmission, while the line fault detection feature enhances system monitoring and proactive maintenance.

    Crafted with a housing width of 12.5 mm, this switch is compact yet powerful, designed to fit seamlessly into space-constrained industrial settings. Its up to SIL 2 safety compliance according to IEC 61508 ensures adherence to stringent safety standards, providing peace of mind for critical operations.

    Equipped with a digital input capability, the P+F KCD2-SR-EX2 supports various input signals, facilitating versatile application across different industries. The switch’s rated voltage of 19 … 30 V DC ensures compatibility with a broad spectrum of power sources, while its low power consumption of ≤ 600 mW contributes to energy efficiency and cost savings.

    For easy and secure connection, the P+F KCD2-SR-EX2 offers screw terminals for 9+, 10- connections, simplifying installation processes. The lightweight design, weighing approximately 100 g, ensures minimal impact on system dynamics and facilitates quick deployment.
