Sensor Type:Precision Optical
Operating Range:Up to 3600mm
Accuracy:±1% of full scale
Operating Temperature:-20°C to +70°C
Environmental Protection:IP67 rated
Supply Voltage:12V to 24V DC
Output Signal:NPN/PNP, TTL/CMOS compatible
Mounting Type:Standard M2 threaded stud
Connectors:M12 connector
Power Consumption:Less than 50mA at 24V DC
The OMRON E6H-CWZ3X(3600PULSE) Precision Encoder is designed for precision in motion control applications, featuring a robust cylindrical mounting option for versatile installation scenarios. Its advanced digital output ensures reliable data transmission even under harsh industrial conditions.
With an impressive resolution of 3600 PPR, this encoder delivers unparalleled accuracy for position and speed monitoring, essential for high-performance machinery and robotics. The open drain digital output facilitates easy integration into various control systems, enhancing system reliability and efficiency.
Engineered to withstand rigorous environments, the encoder operates within a wide temperature range from -20°C to +70°C, ensuring continuous performance in extreme conditions. IP67-rated protection guarantees complete waterproof and dustproof capabilities, making it suitable for outdoor and industrial applications.
For maintenance and troubleshooting, the OMRON E6H-CWZ3X(3600PULSE) offers a user-friendly interface with straightforward diagnostics, allowing quick identification and resolution of any issues. The encoder’s compact design optimizes space utilization, making it an ideal choice for space-constrained applications.
To further enhance compatibility, the encoder supports a variety of power supply voltages ranging from 10 to 30 VDC, ensuring flexibility in different industrial setups. Whether integrating into complex automation systems or standalone machines, the OMRON E6H-CWZ3X(3600PULSE) Precision Encoder is engineered to deliver consistent, accurate, and reliable performance.
