NI NI-9505 Industrial Data Acquisition Module

Manufacturer:National Instruments

Model Number:NI-9505

Module Type:Data Acquisition Module

Channels:32 single-ended or 16 differential

Sampling Rate:Up to 1 MS/s

Resolution:16-bit

Input Range:+/-10V

Compatibility:NI C Series Chassis

Power Supply:5VDC

Operating Temperature:-40°C to +85°C

    The NI NI-9505 is a cutting-edge digital input module engineered for high-reliability industrial environments. This module offers 32 channels of digital input, allowing for extensive data acquisition and monitoring capabilities.

    With a voltage range of 0V to 24V DC, the NI-9505 can interface with a wide variety of sensors and devices commonly found in industrial settings. Its high sampling rate of up to 1 MHz ensures that you capture fast-changing signals without loss of data integrity.

    Equipped with 16-bit resolution, the module delivers precise measurements and ensures consistent performance across a broad range of applications. The power supply requirement is minimal at just 5V DC, making it easy to integrate into existing systems.

    Designed for harsh conditions, the NI-9505 operates within a wide temperature range from -40°C to +85°C, ensuring reliable operation even in extreme environments. Additionally, it features robust isolation protection with a withstand voltage of 2500V AC, providing peace of mind in demanding industrial settings.

    This module is ideal for applications in manufacturing, process control, robotics, and more. With its high performance and reliability, the NI NI-9505 is a valuable addition to any industrial automation system.
