I/O packaged processor board GE IC697BEM731Z

I. System Affiliation

The GE Speedtronic Mark V gas turbine control system is a high-reliability electro-hydraulic control (EHC) system used by GE for steam and gas turbine control. Mark VIe and Mark VIeS are its successor independent controller platforms, employing a single-board processor for simplified processes, integrated power supply, and running on the ControlST software suite.

Core Processor: 80486DX CPU

Storage: DRAM expanded via SIMM slot, flash EPROM storage, ROM BIOS and I/O mapping

Power Supply: +5V DC logic power supply

Communication Interface: 2 RS-232 serial ports, ARCNET network

Core Function: Packs field analog and digital I/O data into COREBUS data packets, broadcasting them to the VME processor at a fast scan rate of approximately 100Hz and a slow scan rate below 100Hz, supporting real-time I/O scanning and redundancy switching without downtime.

Hardware Jumpers: JP1 and JP3 are used for factory testing; JP2 is used to select the 486 bus speed. GE GE F31X139APMALG2FRD1 Module Front View

Software: I/O configuration, FMVED serial download, WATT/VAR pulse input, etc., via TMIA tools.

Application Scenario: GE Speedtronic turbine control system

II. Board Positioning

I/O packaged processor board, which integrates processor functions and I/O interface functions on a single board, belongs to the PC driver board architecture. It features options such as power supply monitoring, dual-channel vibration monitoring, shaft voltage monitoring, and oscillator functionality.

III. Application Scenarios

Industrial automation environments such as gas turbine control, steam turbine control, and combined cycle power plants. This series of boards has been widely used in actual projects such as the Houston suburbs combined cycle power plant for monitoring field signals such as lubricating oil pump status, fire extinguishing contacts, hydrogen seal differential pressure alarms, circuit breaker auxiliary equipment, and float switches.

IV. Technical Specifications Overview

Operating Temperature: 0°C to 60°C

Installation Method: VMEbus backplane slot, single slot occupied

Power Supply: 5VDC backplane power supply, 125VDC excitation

Isolation Class: 2500VAC RMS electrical isolation

Hot-swappable supported

Compliant with CE, UL, CSA, IEC 61000 EMC certifications

V. Related Models in the Same Series

IS220PSCAH1A – I/O Pack, Serial Communication

IS220PSVOH1A – I/O Pack, Servo Control

IS220PTCCH1A – I/O Pack, Thermocouple

IS220PTURH1A – I/O Pack, Steam Turbine

IS210AEBIH3BED – 64-channel isolated discrete input module (also part of the Mark VIe series) GE IC694BEM331C - GE I/O Module

1. GE DS200UCPBG6AFB (Mark V I/O Engine CPU Board)

This is the core I/O processor daughterboard, model UCPB, in the GE Mark V and Mark V LM turbine control systems. It is installed as a daughterboard on the STCA (System Terminal Card Assembly) of each I/O engine, with one board per I/O engine.

Core Processor: 80486DX CPU

Storage: Expanded DRAM via SIMM slot, flash EPROM storage, ROM BIOS and I/O mapping

Power Supply: +5V DC logic power supply

Communication Interface: 2 RS-232 serial ports, ARCNET network

Core Functions: Packs field analog and digital I/O data into COREBUS packets, broadcasting them to the VME processor at a fast scan rate of approximately 100Hz and a slow scan rate below 100Hz, supporting real-time I/O scanning and redundancy switching without downtime.

Hardware Jumpers: JP1 and JP3 are used for factory testing; JP2 is used to select the 486 bus speed.

Software: I/O configuration, FMVED serial download, WATT/VAR pulse input, etc., via TMIA tools.

Application Scenario: GE Speedtronic turbine control system

2. GE IS220PDIOH1A (Mark VIe I/O Packet Processor Board)

This is the GE Mark VIe I/O Packet Processor Board. The VIe series discrete I/O module processor board is part of the PDIO (Discrete Input/Output) package.

Processor: High-speed CPU with flash memory and RAM

Communication: Two independent 10/100 Ethernet ports (ENET1 and ENET2)

I/O Capabilities: Up to 24 contact inputs, up to 12 relay outputs

Input Isolation: Optical isolation up to 1500V, hardware filter 4ms

Operating Temperature: 0 to 60 degrees Celsius

Dimensions: 15.875 cm high x 10.795 cm wide

Function: Connects one or two I/O Ethernet connections to discrete I/O terminal blocks via an electrical interface. The acquisition board collects field signals, which are then logically processed by the processor board and transmitted via Ethernet.

Applications: Suitable for TMR triple redundancy systems and hazardous environments. General 5446772 - GE I/O Module
