GE – Module

Manufacturer:General Electric

Model Number:HWA143-TDM-PMC-V20

Module Category:Communication Module

Interface Type:TDM-PMC

Version:V20

Data Rate:Up to 1 Gbps

Operating Temperature Range:-40°C to +85°C

Power Supply Voltage:12V DC to 48V DC

Communication Protocol:Ethernet, Profinet, Modbus TCP/IP

Dimensions:190mm x 90mm x 45mm

Weight:Approximately 0.8kg

    The GE HWA143-TDM-PMC-V20 is engineered to meet the stringent requirements of modern industrial automation systems. With its advanced data acquisition capabilities, this module ensures precise and reliable data processing, making it an essential component for critical industrial applications.

    This module is designed with a robust and durable build quality, ensuring long-term reliability and minimal maintenance. The compact design allows for easy installation and integration into existing control systems without requiring significant modifications.

    The module supports up to 32 analog inputs and 16 analog outputs, providing versatile connectivity options for a wide range of sensors and actuators. Its high sampling rate of up to 1 MHz enables real-time data acquisition and processing, ensuring optimal system performance.

    With a resolution of 16 bits, the GE HWA143-TDM-PMC-V20 delivers highly accurate and consistent data readings. The module operates over a wide temperature range from -40°C to +85°C, making it suitable for harsh industrial environments.

    Designed for seamless integration with GE‘s Mark VIe System, the HWA143-TDM-PMC-V20 module ensures compatibility and ease of use. Its lightweight design (0.5 kg) and compact dimensions (10 x 6 x 2 cm) make it a space-efficient solution for industrial control systems.
