GE – Board

Manufacturing Company:General Electric

Model:DS200RTBAG2AHC

Category:Relay Terminal Board

Compatible System:Mark V Series Turbine Control Systems

Operating Temperature:0°C to +50°C

Storage Temperature:-40°C to +70°C

Dimensions (WxHxD):178.6 x 104.9 x 78.7 mm

Power Supply:24V DC

Input Current:10 mA max

Output Current:1 A max

Load Resistance:300 Ω

Relay Contacts:SPST

Operating Humidity:5% to 95% non-condensing

    Engineered with precision for seamless integration into GE Fanuc’s Mark V series, the DS200RTBAG2AHC Relay Terminal Board is a high-performance component designed to enhance system reliability and efficiency.

    Crafted from durable high-grade aluminum alloy, this board ensures longevity and robustness against industrial environments.

    Equipped with 8 relays, it offers versatile switching capabilities suitable for various control applications within your facility, ensuring precise control over your operations.

    Featuring an integrated RS-485 communication protocol, the board facilitates efficient data exchange with other components, streamlining your control system’s overall performance.

    Operational in temperatures ranging from -20°C to +55°C, the DS200RTBAG2AHC is built to withstand extreme conditions, making it a reliable choice for diverse industrial settings.

    With its compact size and efficient power supply requirements (DC 24V), this relay terminal board optimizes space utilization and energy consumption, contributing to cost-effective and sustainable operation.
