Allen Bradley – Bradley 1794

Type:Analog Output Module

Model Number:1794-OE8H/B

Channels:8

Bit Depth:12

Operating Voltage Range:5V DC / 24V DC

Output Current Range:0.5mA to 20mA

Load Capacitance:Up to 150nF

Operating Temperature Range:-40°C to +70°C

Power Consumption:Max. 1W per channel

Dimensions (WxHxD):2.75in x 5.13in x 1.37in

Weight:Approx. 0.35lbs

    The AB 1794-OE8H/B is a critical component for enhancing operational efficiency in industrial automation environments. Its compact design, combined with high-speed digital-to-analog conversion, ensures precise control over various processes.

    Featuring eight independent analog output channels, this module allows for versatile configuration, catering to diverse control requirements in manufacturing, packaging, and process industries.

    With a resolution of 12 bits, it offers unparalleled accuracy, enabling fine-tuning of outputs for applications requiring high precision. The DC 24V power supply supports a wide range of industrial devices, ensuring compatibility and flexibility.

    Equipped with an IP20 enclosure, it provides adequate protection against dust and light splashes, ensuring reliable operation in harsh environments. The operating temperature range of -40°C to +70°C ensures durability across different climatic conditions.

    Installation is straightforward, with standard mounting options compatible with Allen-Bradley’s modular architecture, facilitating easy integration into existing systems. This makes the AB 1794-OE8H/B a cost-effective upgrade or replacement choice for improving automation capabilities.
