Allen Bradley – Bradley 1756

Input Type:Discrete

Number of Inputs:16

Communication Cable:16-Point

Voltage Category:24V DC

Operating Voltage Range:20.4…26.4V DC

Current per Point:0.5 A @ 60 °C (140 °F), 1.0 A @ 30 °C (86 °F)

Power Supply:24 Volts DC

Bus Current Draw Max:200 mA

Mounting:DIN Rail or Panel Mount

Certified Product:Yes

    The Allen-Bradley 1756-IB16I is designed to enhance the efficiency of industrial automation processes by providing a robust digital input solution for ControlLogix platforms. Its high-density 16-point configuration allows for extensive connectivity, supporting a variety of industrial applications.

    Equipped with a current sinking mechanism, this module ensures accurate signal interpretation and response, crucial for precise machine control and monitoring tasks. The integrated communication status display offers real-time feedback on operational health, enabling proactive maintenance and optimization.

    With an operating temperature range from -10°C to +55°C, the 1756-IB16I is engineered to withstand harsh industrial environments, ensuring reliability in demanding conditions. It adheres to international safety standards, including UL, CE, CSA, and TUV, guaranteeing compliance and safety in various global markets.

    Installation is straightforward, with a panel mounting design that accommodates easy integration into existing control systems. The use of terminal connectors facilitates quick and secure wiring, simplifying setup and reducing downtime during maintenance or upgrades.

    Optimized for long-term performance and durability, the Allen-Bradley 1756-IB16I is a critical component in enhancing system reliability and efficiency in manufacturing, process control, and automation sectors.
