Allen Bradley – Bradley 1746SC

Model Type:Analog Input Module

Manufacturer:Allen Bradley

Number Of Channels:4

Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:Plus/Minus 7.5 VDC Or 7.5 VAC RMS (Maximum)

Input Range:-20 To 20 MA

Absolute Input Current:-30 To 30 MA (Maximum)

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Range (DC):-10 To 10 VDC – 1 LSB

Current Rating:Backplane Current Draw: 35 MA At 5 V, 85 MA At 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

    The Allen Bradley 1746SC-IN04VI is an indispensable component for enhancing precision and reliability in industrial automation systems. With its high-resolution capabilities, it offers unparalleled accuracy in measuring and controlling critical processes.

    Engineered with robust materials, this module is designed to withstand harsh industrial environments, ensuring continuous operation under demanding conditions.

    Each channel within the module is equipped with advanced circuitry that provides exceptional signal conditioning, reducing noise and interference, leading to more accurate data acquisition.

    For ease of integration, the 1746SC-IN04VI is compatible with various communication protocols, including ControlNet, DeviceNet, and Universal Remote I/O, facilitating seamless connectivity with existing industrial networks.

    In addition to its technical prowess, this module is backed by Allen Bradley’s industry-leading support, offering comprehensive documentation, training resources, and a dedicated customer service team to assist users throughout their project lifecycle.
