Allen Bradley 1746-NIO4V SLC 500 Analog Input & Voltage Output Module, 2 Inputs, 2 Outputs

In stock

The AB 1746-NIO4V SLC 500 Analog Input/Output Module is designed for high-precision analog signal processing in industrial automation systems. It enables seamless integration of control systems by providing precise voltage input and output functionalities, making it ideal for applications requiring precise analog data handling.

Model:1746-NIO4V

Type:SLC 500 Analog Input & Voltage Output Module

Number of Channels:2 Inputs, 2 Outputs

Common Mode Voltage Range (Inputs):-20 To 20 V

Absolute Input Voltage (Inputs):Plus/Minus 7.5 VDC Or 7.5 VAC RMS

Input Range (Current):-20 To 20 MA

Absolute Input Current (Current):-30 To 30 MA

Output Range (Voltage):-10 To 10 V – 1 LSB

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Range (Voltage):-10 To 10 VDC – 1 LSB

Current Rating:Backplane Current Draw: 55 MA

Isolation:Backplane: 500 VDC

The Allen Bradley 1746-NIO4V module offers high-resolution analog input and output capabilities, ideal for applications requiring precise voltage control in industrial automation.

With its robust design, this module ensures reliable operation under demanding conditions, delivering accurate data for enhanced process monitoring and control.

Featuring a backplane current draw of 55 mA, the 1746-NIO4V supports efficient power management and minimizes system-wide energy consumption.

Its open-type enclosure facilitates easy installation and maintenance, ensuring minimal downtime and maximizing operational efficiency.

Equipped with a status LED display, the module provides immediate feedback on operational status, enabling quick troubleshooting and proactive maintenance scheduling.

1746-NIO4V SLC 500 Analog Module 2-Inputs 2-Voltage Outputs
