ABB – Board

Model:WINT2221C

Series:ACS355

Drive Capacity:Up to 2HP

Board Type:Inverter Control Board

Input Voltage Range:85-264V AC

Output Current:Up to 10A

Operating Temperature:-10°C to +50°C

Protection Class:IP66 for harsh environments

Communication Interfaces:RS485, CANopen

Safety Standards:SIL3 compliant

    The ABB WINT2221C ACS355 series drive board is engineered with exceptional compactness, ensuring it fits seamlessly into any industrial setup without compromising on performance. Its uniform design facilitates quick commissioning through application macros and panel assistants, streamlining the setup process.

    Boasting a built-in braking chopper, this drive board ensures smooth transitions between operations, reducing wear and tear on machinery. Additionally, the coated boards provide durability against harsh environmental conditions, making it suitable for outdoor or demanding industrial settings.

    Featuring sensorless vector control technology, the ABB WINT2221C offers unparalleled control over induction and permanent magnet motors. This feature allows for precise speed and torque adjustments, optimizing energy usage and enhancing operational efficiency.

    For environments where safety is paramount, the inclusion of a Safe Torque Off function (SIL3) as standard provides an additional layer of protection, ensuring reliable operation in critical systems.

    Available in both standard and IP66 variants, the ABB WINT2221C ACS355 series drive board caters to a wide range of applications, from manufacturing floors to outdoor solar pump drives, ensuring reliability and performance across various sectors.
