ABB – Board

Model:UC86-8CH

Manufacturer:ABB

Application Type:Counting & Measurement

Processing Capacity:Up to 8 channels

Operating Voltage:24V DC

Frequency Range:1 MHz

Accuracy:±0.01% of reading + 2 counts

Operating Temperature:-20°C to +55°C

Storage Temperature:-40°C to +70°C

Dimensions (mm):86 x 58 x 20

Weight (kg):0.2

Communication Interface:RS-485

    The ABB Universal Counter Board UC86-8CH, model 57275871, is engineered to deliver unparalleled precision in industrial measurement tasks. This compact yet powerful counter board supports up to 8 channels, each capable of measuring frequencies up to 1 MHz with an exceptional accuracy of +/- 0.05%.

    Equipped with a robust RS-485 communication interface, it ensures seamless data transfer and compatibility with various industrial control systems. The board operates efficiently on a wide voltage range of DC 5V to 24V, ensuring reliable performance under varying power conditions.

    With its low power consumption of less than 10 mW, this board is energy-efficient, making it ideal for applications where power usage is a concern. The compact design with dimensions of 65mm x 86mm x 22mm fits seamlessly into tight spaces, enhancing system integration.

    Operating within a temperature range of -20°C to +70°C, the board is built to withstand harsh industrial environments. Its ability to function in extreme conditions makes it suitable for a wide range of applications, from manufacturing floors to outdoor installations.

    Featuring a relative humidity tolerance of 5% to 95% RH without condensation, the board maintains its functionality even in damp or humid environments. This makes it a reliable choice for industries where moisture levels can fluctuate significantly.
