ABB – Module

Protocol:Twisted Pair Communication

Operating Frequency:100 Kbps

Network Compatibility:Advant Fieldbus 100 (AF100)

Dimensions:117 x 45 x 148.5 mm

Weight:0.73 kg

Certification:CE, UL

    The ABB TC512 3BSE006383R1 Twisted Pair Modem is engineered to deliver high-speed, reliable data transmission over standard twisted pair cables, ensuring seamless integration into existing factory networks. Its robust design withstands harsh industrial environments, maintaining performance under extreme temperatures and humidity conditions.

    Featuring a compact and durable housing, this modem is ideal for space-constrained areas within manufacturing plants. It supports various modulation schemes, including Manchester encoding, optimizing data transfer rates up to 1 Mbps, making it suitable for diverse applications from simple control loops to complex distributed control systems.

    Equipped with an extended operating voltage range of 24V DC, the TC512 modem ensures compatibility with a wide variety of power sources typically found in industrial settings. This flexibility reduces installation complexity and minimizes maintenance requirements.

    With a maximum cabling distance of 1200 meters, this modem enables long-distance communication without the need for repeaters or additional infrastructure, significantly reducing costs associated with network expansion.

    Designed with ease-of-use in mind, the ABB TC512 3BSE006383R1 Twisted Pair Modem offers straightforward setup and configuration processes, allowing technicians to quickly integrate it into their existing systems without extensive training. Its compatibility with RS-485 protocols ensures seamless interoperability with a broad range of industrial devices and systems.
