ABB – Module

Model Type:IMAS102

Product Brand:ABB

Module Type:Analog Input

Application Environment:Indoor industrial environments

Operating Voltage:24V DC

Data Acquisition Rate:1000 samples per second

Accuracy Range:±0.01% of full scale

Input Signal Range:-5 to +5 VDC

Number of Channels:8

Dimensions (LxWxH):100mm x 90mm x 25mm

Weight:0.2kg

Connection Type:Terminal block

Temperature Range:-20°C to +70°C

    The ABB IMAS102 Analog Input Module is engineered with precision and reliability for seamless integration into modern industrial automation systems. This module boasts 16 channels capable of handling a wide range of analog signals, ensuring accurate and timely data acquisition for critical process control.

    With a versatile signal range from -10V to +10V or 0V to 10V, it accommodates diverse sensor outputs, making it suitable for a multitude of applications across different industries. Its sampling rate of up to 1 kHz guarantees real-time monitoring capabilities without compromising on precision.

    Energy efficiency is a key feature, with a maximum power consumption of just 20 mA, allowing for extended operation without overloading the system. The module is designed to operate within a broad temperature range of -20°C to +70°C, ensuring durability and reliability in challenging environments.

    The IP20 enclosure type offers basic protection against dust and non-corrosive materials, suitable for indoor industrial settings. For communication, it supports MODBUS RTU, facilitating easy integration with other industrial devices and systems.

    This module is a testament to ABB‘s commitment to innovation and quality, providing engineers and automation specialists with a robust solution for enhancing process control and efficiency in their operations.
