Dimension:105mm x 65mm x 15mm
Weight:150g
Operating Temperature Range:-20°C to +60°C
Input Voltage:DC 24V
Output Current:5A max
Communication Protocol:MODBUS RTU, CANopen
Memory Capacity:512KB Flash Memory
Number of Inputs/Outputs:16 Inputs / 16 Outputs
Environmental Standards:IP20 Rated
Certifications:CE, UL, ISO 9001:2015
The ABB HIER460279R1/f UN0901d V1 PCB Circuit Board is engineered to meet the stringent demands of industrial environments. It offers exceptional performance with its robust design, ensuring reliability even under harsh conditions. This PCB is ideal for integration into complex control systems, providing seamless data exchange through its efficient RS-485 interface at up to 1 Mbps transfer rate.
Crafted from high-quality industrial-grade FR4 material, this circuit board ensures durability and excellent electrical insulation, making it suitable for a wide range of applications. With a compact size and lightweight construction, it can be easily integrated into various machines without compromising on functionality.
Featuring 16 channels, this PCB supports diverse input types, enabling versatile use across different industrial sectors. Each channel is equipped to handle up to 1A of current, allowing for efficient power distribution and control of actuators or sensors.
Operating within a temperature range of -20°C to +60°C, this PCB maintains stable performance throughout the year, regardless of environmental fluctuations. Its DC 24V input voltage specification ensures compatibility with most industrial power supplies, further enhancing its application flexibility.
Equipped with advanced diagnostics capabilities, the ABB HIER460279R1/f UN0901d V1 PCB Circuit Board facilitates easy troubleshooting and maintenance, reducing downtime and enhancing operational efficiency. It is an indispensable component for achieving precision control and automation in modern manufacturing processes.
