ABB DSQC233 YB560103-BS/1 – Advanced Axis Control Module

Operating System Compatibility:ABB Robotware, ABB Ability™

Maximum Input Signals:24

Maximum Output Channels:16

Processing Speed (Hz):64KHz

Power Supply Voltage:DC 24V

Communication Protocol:EtherCAT

Dimensions (mm):120 x 100 x 20

Weight (kg):0.25

    The ABB DSQC233 YB560103-BS/1 Axis Board is engineered to deliver exceptional performance in motion control tasks. Its compact design ensures easy integration into existing systems without compromising on functionality.

    Equipped with advanced EtherCAT communication interface, this board supports high-speed data transfer and synchronization, enabling precise control over multiple axes simultaneously.

    Featuring a robust power supply and capable of handling up to 1.5 A per channel, the DSQC233 YB560103-BS/1 ensures reliable operation even under demanding conditions.

    With an operating temperature range from -20°C to +60°C, it is suitable for a wide variety of industrial settings, from cold warehouses to hot manufacturing floors.

    Designed for panel mounting, the board saves space and facilitates quick installation and maintenance, making it a preferred choice for engineers seeking efficient and compact solutions.
