ABB DSDO301 | 57160001-CC | MASTER Digital Output Board

Operating Voltage:DC 24V

Current Rating:2A

Number of Outputs:16

Connection Type:M12 connector

Operating Temperature Range:-25°C to +60°C

Communication Interface:Modbus RTU

Relay Configuration:Single-pole double-throw (SPDT)

Load Capacity:Up to 5A per channel

Reliability Rating:IP20

Module Dimensions:125mm x 102mm x 51mm

    Integrating advanced digital signal processing technology, the ABB DSDO301 57160001-CC MASTER Digital Output Board offers unparalleled performance for high-demand applications. Designed for seamless integration into existing industrial control systems, this board ensures consistent and reliable operation under extreme conditions.

    With its robust 24V DC power supply, the board supports up to 16 digital outputs, enabling versatile control over actuators, sensors, and other critical components. Its ultra-fast response time of less than 1ms ensures minimal delay in system operations, enhancing overall efficiency.

    Featuring support for leading communication protocols like Profibus DP and DeviceNet, the DSDO301 board facilitates easy connectivity with a wide range of devices and systems, streamlining integration and setup processes.

    Engineered for reliability, this digital output board operates within a temperature range of -20°C to +60°C, ensuring stable performance in diverse environmental conditions. It is designed for long-term storage in temperatures from -40°C to +85°C, guaranteeing ease of handling during deployment.

    Compact yet powerful, the board measures 100mm x 80mm x 20mm and weighs only 0.3kg, making it an ideal choice for space-constrained environments without compromising on functionality. Its lightweight design also simplifies installation and maintenance.
