ABB 5443013 – Relay Module

Module Type:Digital Output

Module Designation:DO86-16

Model Number:5760852-8G

Manufacturing Brand:ABB

Operating Voltage Range:24VDC

Current Rating:16A

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

Mounting Type:Panel Mount

Dimensions (WxHxD):52mm x 45mm x 15mm

Weight:0.05kg

Connection Type:Terminal Block

Number of Outputs:16

Communication Interface:Modbus RTU

Input/Output Separation:Electrical

Relay Type:SPST

Relay Contact Rating:10A @ 24VDC

    The ABB DO86-16 Stromberg Digital Output Board is specifically engineered for industrial applications, providing robust and reliable digital output control under extreme conditions. With its wide operating temperature range, it ensures stable performance in both cold and hot environments, making it ideal for outdoor or challenging industrial settings.

    Featuring 16-channel digital outputs, this board offers high current capability and contact durability, ensuring consistent and accurate control signals. Its TTL signal type is compatible with a variety of industrial control systems, enhancing integration flexibility.

    Equipped with an RS-485 communication interface, the board supports Modbus RTU protocol, enabling seamless data exchange with other devices in the network. This feature facilitates easy setup and management, streamlining the control system architecture.

    Compliance with EN 61010-1 safety standard ensures the board meets stringent electrical safety requirements, providing users with peace of mind regarding operator safety and equipment integrity.

    Designed with compact dimensions, the ABB DO86-16 Stromberg Digital Output Board is lightweight yet sturdy, making it a practical choice for space-constrained applications. Its high-quality materials and construction guarantee long-term reliability and minimal maintenance requirements.
