ABB CH308802 – Module

Product Type:Analog Output Module

Manufacturer:ABB

Model Number:CH-308802 | 3BHE022455R1101

Module Type:Discrete Output

Operating Voltage Range:12-24VDC

Current Rating:50mA per channel

Temperature Range:-25°C to +60°C

Communication Interface:MODBUS RTU

Dimensions:52.5mm x 55.5mm x 8mm

Weight:15g

Connection:M8 x 0.8mm screw terminals

    The ABB CH-308802 3BHE022455R1101 Analog Output Module is an essential component for modern industrial control systems, ensuring seamless integration with PLCs and other automation devices.

    Featuring a wide range of 0mA to 20mA current output, it provides precise control over actuators and sensors, critical for process monitoring and control.

    With its ±1% accuracy, this module ensures reliability and consistency in your automation processes, minimizing errors and enhancing system efficiency.

    Capable of handling loads up to 250 Ohms, it offers flexibility in various applications, from temperature control to flow regulation, making it suitable for a broad spectrum of industries.

    Equipped with Modbus RTU communication interface, it seamlessly connects to a wide range of industrial networks, facilitating easy data exchange and remote monitoring capabilities.

    Operated within a temperature range of -25°C to +70°C and stored within -40°C to +85°C, this module is designed for durability and reliability in challenging industrial environments.
