ABB – Board

Type:Servo Control Board

Manufacturer:ABB

Model Number:8750 0451-58 DSQC136

Interface:EtherCAT

Operating Voltage:24V DC

Current Capacity:Up to 2A

Communication Protocol:CANopen

Number of Channels:4

Operating Temperature Range:-20°C to +60°C

Storage Temperature Range:-40°C to +85°C

Dimensions (WxHxD):120mm x 32mm x 95mm

Weight:0.1kg

    The ABB 8750 0451-58 DSQC136 SERVO BOARD is engineered to provide unparalleled precision and reliability in motion control applications. This state-of-the-art component is part of ABB‘s comprehensive suite of automation solutions, designed to enhance productivity and reduce operational costs.

    With its compact design and robust construction, the DSQC136 SERVO BOARD seamlessly integrates into a variety of industrial setups, offering a flexible solution for complex automation tasks. Its high-resolution digital pulse width modulation capabilities enable smooth, accurate positioning and velocity control.

    Featuring a wide operating temperature range (-20°C to +60°C), the DSQC136 is suitable for a broad spectrum of industrial environments. The board supports RS-232 communication, facilitating seamless integration with other ABB automation products and third-party systems.

    Each channel on the DSQC136 is equipped with a 2A load capacity, allowing for efficient power distribution and handling of heavy-duty actuators. This ensures reliable operation even under demanding conditions, making it a preferred choice for applications requiring high precision and stability.

    In addition to its technical prowess, the DSQC136 SERVO BOARD is manufactured using high-quality materials, ensuring durability and longevity. Its modular design allows for easy installation and maintenance, further enhancing its value proposition in industrial settings.
