OMRON CP1H-XA40DT1-D Chassis Mount Control Module

Number of Ports:24 Input, 16 Output

Power Supply Voltage:24VDC

Counter Speed:High-Speed Counters

Interrupt Inputs:8 Built-in Interrupt Inputs

Processing Speed:Approximately 500 Instructions per Second

Serial Communication Ports:Two Ports, Selectable RS-232C or RS-485 Option Boards

Safety Standards:CSA, UL (cULus), CE, RCM, and KC Registration

Operating Voltage Range:20.4 to 28.8 VDC

Leakage Current:0.1 mA Max

Common I/O Configuration:PNP Internal I/O Common

    The OMRON CP1H-XA40DT1-D Control Module is engineered to provide superior control logic capabilities for a wide range of industrial applications, including but not limited to, robotic arms, CNC machinery, and automated production lines. Its robust design ensures high accuracy and efficiency, making it an indispensable tool for manufacturers seeking to optimize their processes.

    This module boasts pulse outputs for up to four axes, providing precise control over actuators and motors. The high-speed counters, along with differential phases for each axis, enable smooth and accurate motion control, even in high-speed operations. This feature is particularly advantageous in applications requiring rapid response times and tight control tolerances.

    Equipped with eight interrupt inputs, the CP1H-XA40DT1-D facilitates faster processing and improved system responsiveness. The inclusion of this feature allows for more efficient handling of external events and inputs, enhancing the overall performance of the automation system.

    In terms of communication, the control module supports serial communications through two ports, offering flexibility in connection options. Users can choose between RS-232C and RS-485 option boards, ensuring compatibility with a broad range of equipment and systems.

    Safety and compliance are paramount in industrial automation. The CP1H-XA40DT1-D adheres to international safety standards, including CSA, UL (cULus), CE, RCM, and KC Registration. These certifications guarantee that the module meets stringent safety requirements, providing peace of mind for users in various geographical regions and industries.
