Humidity Withstand:Up to 90%, non-condensing
RTD Inputs:3-wire: 100 Ω Platinum, 100 Ω Nickel, 120 Ω Nickel, 10 Ω Copper
Series:469 Motor Management Relay
Phase Current:5 A
Phase CT Secondaries:5
Control Power:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
Analog Outputs:Four (4) 4 to 20 mA
Display:Enhanced display, larger LCD
Current:390/500 MA (MAX)
Line Voltage:90-300VDC, 70-265VAC
Enclosure Rating:20-X
Frequency:48-62 HZ
Overvoltage Category:II
Insulation Voltage:300 V
Pollution Degree:2
The GE SR469-P5-HI-A20-E is a sophisticated Motor Management Relay designed specifically for the protection and management of medium to large motors. With its advanced monitoring capabilities, this relay ensures optimal performance and longevity of your motor systems. Equipped with multiple RTD inputs, it accurately determines the temperature and hottest point of the motor system, enabling precise thermal management. The relay operates efficiently within a wide range of control power voltages and frequencies, making it suitable for various industrial applications. Its robust design, including conformal coating for harsh environments, ensures reliable operation even under challenging conditions. The enhanced front panel display provides clear and comprehensive information, simplifying operational oversight. With four analog outputs and nine opto-isolated digital inputs, the GE SR469-P5-HI-A20-E offers versatile connectivity options, enhancing system integration and flexibility. Additionally, the relay supports software like EnerVista 469 Setup for easy configuration and maintenance. Whether you’re managing industrial motors in chemical plants, manufacturing facilities, or other demanding environments, the GE SR469-P5-HI-A20-E delivers unparalleled reliability and performance.
