Brand:B&R
Model:4P3040.00-490
Operating Voltage:220 V
Output Frequency:50 kHz
Certified Product:4P3040.00-490
Series:4P3040.00-490
Product Code:4P3040.00-490
Interface:1 RS232, 1 CAN (electrically isolated)
Inputs:10 digital inputs (24 VDC)
Outputs:8 digital outputs (24 VDC, 0.4 A)
Protection Rating:IP65 (from front)
Dimensions:205 × 220 mm (WxH)
Weight:N/A
Power Supply:24 VDC
Display:5.7 inch QVGA monochrome LCD
Soft Keys:8 softkeys
Function Keys:32 function keys
System Compatibility:2003 CPU
Memory:700 KB SRAM, 1.4 MB FlashPROM
Expansion Slots:1 PCMCIA slot, 6 slots for screw-in modules
The B&R 4P3040.00-490 Power Panel is a highly advanced and durable industrial touchscreen monitor designed to withstand harsh industrial environments. With its robust design and comprehensive feature set, it ensures reliable operation even under challenging conditions. The 5.7-inch QVGA monochrome LCD display provides clear visibility, while the 8 softkeys and 32 function keys offer intuitive navigation and control. The system is fully compatible with 2003 CPU, providing seamless integration with existing systems. The Power Panel features a built-in 1 RS232 and 1 CAN interface, both electrically isolated and network-capable, ensuring reliable communication and data transfer. It includes 6 slots for screw-in modules, allowing for flexible expansion and customization. Additionally, the unit is equipped with 10 digital inputs and 8 digital outputs (24 VDC, 0.4 A), making it suitable for a wide range of industrial applications. The protection rating of IP65 from the front ensures dust and water resistance, making it ideal for use in dusty or wet environments. The Power Panel operates on 220 V and has an output frequency of 50 kHz, ensuring optimal performance in industrial settings.
