Allen-Bradley 1746-HSTP1: High-Performance Stepper Control Module

Type:Stepper Control Module

Model Number:1746-HSTP1

Manufacturer:Allen Bradley

Power Supply Voltage:24V DC

Input Current:Less than 25mA

Output Current:Up to 0.5A

Operating Temperature Range:-10°C to +60°C

Communication Interface:RS-485

Enclosure Type:IP20

Connection Ports:1 x DB-9 connector

Load Capacity:100 ohms

Control Protocol:Modbus RTU

    Integrating advanced microcontroller technology, the Allen Bradley 1746-HSTP1 Stepper Control Module ensures precise, reliable operation for a wide range of stepper motor applications in the manufacturing sector.

    This module boasts an impressive resolution of 256 microsteps, allowing for highly accurate positioning and smooth motion control, making it ideal for precision machinery and robotics.

    Equipped with an RS-485 communication interface, it seamlessly integrates into existing industrial networks, facilitating easy setup and configuration.

    The compact IP20 open frame design allows for flexible installation on various panels, while its robust construction withstands demanding industrial environments.

    With its wide operating temperature range (-20°C to +60°C), this module is suitable for use in diverse geographical locations and industrial settings, ensuring continuous performance under varying conditions.
