Advanced 1756-L72S GuardLogix Processor: Industrial Control Excellence with Scalable Performance

Processor Type:GuardLogix

Model Number:1756-L72S

Manufacturer:Allen-Bradley

Memory (MB):10

Safety Memory (MB):4

I/O Memory (MB):0.98

Optional Non-Volatile Memory Storage:[“1 GB (1756-SD1)”,”2 GB (1756-SD2)”]

Mounting:Chassis

Isolation:30 V (Continuous)

Basic Insulation:

USB Port To Backplane:Yes

Type Tested At 500 VAC For 60 SEC:

Enclosure:Open Type

RFI Suppression:[“Radiated: 10 V/M With 1 KHZ Sine-Wave 80% AM From 80 – 2000 MHZ”,”10 V/M With 200 Hz 50% Pulse 100% AM At 900 MHZ”,”10 V/M With 200 Hz 50% Pulse At 900 MHZ”]

Weight (kg):0.92

    The Allen-Bradley 1756-L72S GuardLogix Processor is engineered to deliver unparalleled performance and reliability in demanding industrial settings. This processor integrates advanced safety features seamlessly within its design, ensuring compliance with stringent safety standards without compromising operational efficiency.

    With its large memory capacity, the 1756-L72S can handle complex control algorithms and vast data processing requirements, making it suitable for high-speed, multi-tasking applications in the manufacturing sector. The integrated safety system ensures continuous operation even under hazardous conditions, providing a robust solution for plant safety management.

    Featuring a compact chassis mounting option, this processor is designed for easy integration into existing control systems. Its open-type enclosure provides adequate ventilation, ensuring stable operation in various environmental conditions. The inclusion of an optional non-volatile memory storage up to 2 GB enhances data retention capabilities, critical for process optimization and troubleshooting.

    RFI suppression technology ensures minimal interference from electromagnetic sources, maintaining signal integrity and preventing potential disruptions in sensitive control operations. This feature is particularly beneficial in environments where electrical noise is prevalent, such as near power lines or machinery.

    For communication-intensive applications, the processor includes a USB port that connects directly to the backplane, facilitating rapid data exchange between the controller and other devices. The lightweight design, weighing only 0.92 kg, makes it easy to handle during installation and maintenance processes, while the communication module adds flexibility with a weight of just 0.3 kg.
