Operating Voltage:24 VDC
Input Range:-10 V to +10 V
Sampling Rate:Up to 1000 Hz
Resolution:14-bit
Power Consumption:Max 25 mA
Communication Interface:DeviceNet, Profinet
Environmental Temperature:-20°C to +70°C
Protection Class:IP20
Connection Type:Pin Header
Number of Channels:2
Certifications:CE, UL, CSA, TUV
Crafted with precision and reliability, the ABB 63NHG00B-690 3ABD00017823 Differential Analog Input Module is designed to meet the stringent requirements of industrial automation environments. Its dual-channel configuration ensures accurate simultaneous measurements of differential voltage inputs, facilitating real-time data processing for improved operational efficiency.
Equipped with an advanced 12-bit resolution ADC, this module offers unparalleled accuracy and sensitivity, making it ideal for applications requiring high-fidelity signal acquisition. The module supports a wide operating voltage range, from 5V to 30V DC, ensuring compatibility with various power supplies found in diverse industrial settings.
With a sampling rate of up to 10 kHz, it can capture rapid changes in signals without missing critical information, which is crucial for processes involving dynamic fluctuations. This feature makes it particularly suitable for applications in chemical processing, manufacturing, and process control where precision timing is essential.
Built to withstand harsh environmental conditions, the module operates reliably within a temperature range of -20°C to +85°C, ensuring continuous performance even under extreme temperatures. The compact size and panel-mount design facilitate easy integration into existing control systems, minimizing installation time and complexity.
The ABB 63NHG00B-690 3ABD00017823 is also equipped with DeviceNet communication interface, enabling seamless connectivity with other devices in the network. This facilitates efficient data exchange and control commands, enhancing overall system interoperability and reducing setup time.
