Operating Voltage:600V
Current Rating:120A
Switching Frequency:50kHz
Thermal Resistance:≤1°C/W
Insulation Resistance:≥10MΩ
Operating Temperature Range:-40°C to +170°C
Package Type:TO-247
Cooling Method:Air Cooled
Certifications:[“IEC 60950″,”UL 60950”]
These IGBT modules are engineered with advanced semiconductor technology to provide superior reliability and longevity in harsh industrial environments. They feature a robust design that ensures stable operation across a wide range of temperatures, from -40°C to +170°C, ensuring reliable performance in even the most demanding conditions.
With an operating voltage of 600V and a current rating of 120A, these modules are capable of handling high-power loads efficiently. Their ability to switch at a frequency of 50kHz enables precise control over power distribution, making them suitable for applications in motor drives, renewable energy systems, and power conversion equipment.
The modules come equipped with a thermal resistance of ≤1°C/W, ensuring effective heat dissipation through air cooling, which is critical for maintaining optimal operational conditions. Additionally, they boast an insulation resistance of ≥10MΩ, providing excellent electrical isolation and safety in industrial circuits.
Certified to international standards such as IEC 60950 and UL 60950, these IGBT modules meet stringent safety and quality requirements, assuring users of their reliability and compliance with industry regulations.
ABB’s 2MBI600VX-120-50 IGBT Modules are designed for seamless integration into existing industrial systems, offering easy installation and compatibility with a wide range of control interfaces. They are an excellent choice for enhancing the efficiency and performance of automation systems in industries such as manufacturing, automotive, and energy generation.
