Input Voltage (AC):230 to 480 Voltage, 3-Phase
Input Frequency (AC):47 to 63 Hertz
Nominal Input Current (AC):11 Amperes (0-peak) Continuous, 22 Amperes (0-peak) Intermittent
Size:9.54 x 14.2 x 5.46 inches (242.2 x 360.7 x 138.7 mm)
Supported Interfaces:RS232, RS485 with DeviceNet
Multi-turn Absolute Encoders:Supplies external logic power and maintains precision
Auxiliary Power Supply:Yes
Internal Shunt Resistance:40 Ohms
Weight:22.96 pounds
Engineered for simplicity and efficiency, the Allen-Bradley 2098-DSD-HV150-SE SERCOS Servo Drive is a powerhouse for advanced motion control systems. Its compact design ensures easy integration into various industrial setups, enhancing productivity and performance.
Featuring a dedicated slot for RS232 and RS485 with DeviceNet support, the drive seamlessly communicates with ControlLogix Programmable Automation Controllers (PAC) and SOFTLogix controllers, leveraging the Serial Real-Time Communication System (SERCOS) protocol for unparalleled control.
With support for multi-turn absolute encoders, the drive ensures precise positioning and operation, enabling the delivery of external logic power and maintaining accuracy in demanding applications.
Equipped with a 40 Ohm internal shunt resistance and auxiliary power supply, the 2098-DSD-HV150-SE is designed to withstand rigorous conditions without compromising on performance. Its robust construction and efficient power management make it a reliable choice for industrial environments.
Weighing in at 22.96 pounds, the drive is lightweight yet sturdy, making it a practical solution for space-conscious industrial setups. Its comprehensive feature set, coupled with compatibility across multiple platforms, ensures that the Allen-Bradley 2098-DSD-HV150-SE SERCOS Servo Drive delivers exceptional motion control performance, setting new benchmarks in industrial automation.
