Operating Temperature:-40°C to +85°C
Signal Range:±10V, ±5V, 0-10V, 4-20mA
Input Impedance:High, ensuring minimal load effect on the measurement circuit
Output Resolution:16-bit, providing exceptional detail in signal representation
Isolation Voltage:1000VDC, ensuring safe operation across different voltage levels
Communication Interface:RS-485, enabling robust data exchange in industrial networks
Power Consumption:≤ 1W, efficient operation without additional power supplies
Dimensions:75mm x 65mm x 20mm, compact design for easy integration
Connectors:Industry-standard 9-pin D-sub connector for seamless connection
The ABB 1771-NR High Resolution Isolated Analog Modules are engineered to deliver exceptional performance in demanding industrial environments. These modules boast a 16-bit resolution, ensuring high accuracy in data conversion from analog to digital signals. With an isolation voltage of 2000V, they provide robust protection against electrical noise and interference, guaranteeing reliable operation even in harsh conditions.
Featuring a wide input range from -10V to +10V, these modules can accommodate various sensor types and applications across different industries. Their versatile output range of 0V to 10V facilitates seamless integration into control systems, enabling precise control over actuators and other components.
Designed for optimal performance within the temperature range of -40°C to +85°C, these modules are suitable for use in extreme environments. Moreover, their power consumption is kept below 1W, contributing to energy efficiency and cost-effectiveness.
Equipped with support for leading communication protocols such as DeviceNet, EtherCAT, and Profinet, these modules ensure smooth interoperability with a wide array of industrial devices. This feature enhances system scalability and compatibility, making them ideal for integration into complex automation setups.
Crafted with durability and reliability in mind, the ABB 1771-NR High Resolution Isolated Analog Modules are built to withstand rigorous industrial usage. They are an essential component for achieving precision control in applications requiring high accuracy and operational dependability.
