Input Type:Discrete
Number of Inputs:16
Communication Cable:16-Point
Voltage Category:24V DC
Operating Voltage Range:20.4…26.4V DC
Current per Point:0.5A @ 60°C, 1.0A @ 30°C
Power:24 Volts DC
Bus Current Draw, Max:200mA
Mounting:DIN Rail or Panel Mount
Resolution:320 MICRO-V/Count
Rejection Ratio:Normal Mode Noise > 80 DB, Common Mode Noise > 100 DB
Slot Width:1
Experience unparalleled precision with the AB 1756-IB16IF Analog Input Module, specifically engineered for the stringent demands of industrial environments. This module ensures reliable data acquisition, making it a critical component in your Allen-Bradley ControlLogix system.
Featuring a wide voltage range of 10-31VDC, this module offers exceptional versatility, catering to diverse industrial settings. Its resolution of 320 MICRO-V/Count at Plus/Minus 10.25 V and its noise rejection ratios exceeding 80 dB and 100 dB respectively, guarantee accurate measurements under challenging conditions.
Designed with durability in mind, the AB 1756-IB16IF operates efficiently within a temperature range of -40°C to +70°C, ensuring continuous performance in extreme environments. The module’s power consumption of 2.3 W and current consumption of 3.9 W are optimized for energy efficiency, making it a cost-effective choice for your automation projects.
Installation is straightforward with the AB 1756-IB16IF, which can be easily mounted on a DIN rail or directly on a panel, thanks to its compact design and versatile mounting options. This flexibility enhances the adaptability of your control system, allowing for efficient setup and maintenance.
Backed by the trusted reputation of Allen-Bradley, the AB 1756-IB16IF Analog Input Module delivers on reliability and performance. It seamlessly integrates into your existing ControlLogix ecosystem, enhancing the overall functionality and efficiency of your industrial automation processes.
