AB 1746-INT4 Analog Input Module

Product Type:Analog Input Module

Manufacturer:AB (Allen-Bradley)

Model Number:1746-INT4

Number of Channels:4

Common Mode Voltage Range:-20 to 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)

Input Range:-10 to 10 VDC – 1 LSB

Absolute Input Current:-30 to 30 mA (Max.)

Voltage Rating:Overvoltage protection: 7.5 VAC RMS

Current Rating:Backplane current draw: 35 mA at 5 V, 85 mA at 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

Operating Temperature:-40°C to +70°C

Power Consumption:Less than 2 W

    The Allen Bradley 1746-INT4 Analog Input Module is engineered to deliver unparalleled precision and reliability in industrial environments. With its advanced signal processing capabilities, this module ensures accurate data acquisition, critical for real-time monitoring and control applications.

    Featuring a compact design that accommodates multiple channels within a single unit, it offers flexible installation options, making it suitable for space-constrained environments. The module is built to withstand harsh industrial conditions, ensuring durability and longevity.

    Engineered with high-resolution technology, the 1746-INT4 excels in measuring subtle variations in analog signals, making it ideal for applications requiring high sensitivity and accuracy. It supports a wide range of input voltages and currents, providing compatibility with various industrial sensors and equipment.

    For enhanced system integration, the module includes built-in communication ports for EtherNet/IP, DH+, DH-485, or RS-232 interfaces. This enables seamless connectivity with other Allen Bradley devices, third-party systems, and networked solutions, facilitating comprehensive automation and data exchange.

    The Allen Bradley 1746-INT4 Analog Input Module is backed by industry-leading technical support and a comprehensive warranty, ensuring peace of mind for users. Its reliability, combined with user-friendly installation and maintenance procedures, makes it an excellent choice for enhancing operational efficiency and productivity in manufacturing and process control settings.
